Dings Stationary Electromagnets

If Tramp Metal is Rare in Your Process but Must be Removed then… Sometimes Simpler is Better.

Dings Stationary Electromagnet Installed

Dings Overhead Stationary Electromagnet’s deep penetrating magnetic field removes metal contaminants from your product stream before they damage your conveyors, crushers, screens, and other processing equipment. Dings Stationary Electromagnets are engineered for optimum performance, reliability, and durability. With no moving parts they are virtually maintenance-free. Just check the cooling oil. No belt or drive motor allows for a lower suspension height. This may make the use of a smaller, more economical magnet possible.

Stationary Electromagnet

What makes Dings co. Electromagnets better than the rest? It’s our unique coil design and Industry Best 20-Year Warranty on Coil Burnout.

• No insulation is needed with anodized aluminum straps–eliminating the major cause of coil failure (insulation breakdown)
• More magnetism and separating power – generated by extra turns
• Each turn is exposed to oil-cooling – assuring a stronger, more efficient magnet
• Eliminates the need for external oil expansion pipes or tanks that require maintenance and can be damaged.
